SmartlockPro® 7599-HGI Duplex GFCI Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, Ivory
SmartlockPro® 7599-HGI Duplex GFCI Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, Ivory
SKU: LEV7599-HGI
Manufacturer Part Number: 7599-HGI
UPC: 078477317075
Documents
Features
- Max 30 C after 50 cycles OL at 150 percent rated current
- Rated V-2 per UL94
- Nylon face, brass 10-32 terminal screws, brass 8-32 grounding screw, zinc-plated steel yoke, zinc-plated steel clamp nuts
- Brass-hot, green-ground, white-neutral terminal ID
- Diagnostics with indicator light
- GFCI ground fault
- Buttons match face
- Back and side wired
- 20 A feed-through
Specification
| Grade | Hospital |
|---|---|
| Material | Nylon |
| NEMA Rating | NEMA 5-15R |
| Number Of Poles | 2 |
| Number of Wires | 3 |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Amperage Rating | 15 A |
| Catalog ID | LEV7599-HGI |
| Color | Ivory |
| Dimensions | 4.21 in H x 1.31 in W x 1.19 in D |
| Temperature Rating | -35 to 66 deg C |
| Terminal Type | Screw |
| Voltage Rating | 125 VAC |
| Standard & Approvals | NEMA WD-6, ANSI C-73, UL498HG File E13399, CSA C22.2 NO 42 File LR-57811, NOM 057 |
| Includes | Steel Strap, Nylon Wallplate and Screws |
