Leviton® SmartlockPro® Slim® GFRBF-W Blank Self-Test Slim GFCI Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, White

Selected Leviton® SmartlockPro® Slim® GFRBF-W Blank Self-Test Slim GFCI Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, White
Leviton® SmartlockPro® Slim® GFRBF-W Blank Self-Test Slim GFCI Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, White

Documents

Short Description

The SmartlockPro® self test GFCI tests itself even if you forget. Designed to meet the latest UL standard for auto monitoring (self test) our complete line of self test GFCIs periodically conduct an automatic internal test to confirm that it can respond to a ground fault. With the slimmest profile on the market, the device allows for fast and easy installation, while Leviton® patented reset lockout mechanism prevents reset of the GFCI if it is not wired or operating correctly. The SmartlockPro® self test GFCI is the smart choice in ground fault circuit interrupter protection.

Features

  • Provides continuous ground fault protection detects and trips on actual ground fault even when self-test is being conducted
  • On initial power up, tests the GFCI within 3 sec
  • Auto monitoring exceeds the UL requirement
  • Auto adapts and shifts to more frequent testing if potential problem is detected
  • Status indicator light provides simple, intuitive feedback on power and protection status as well as indication of line/load reversal
  • Patented lockout action prevents reset if GFCI is damaged and cannot respond to a ground fault
  • Electronics are designed to minimize any false triggers
  • Reduced depth makes it easier to install in any electrical box, even shallow ones
  • Terminals allow for easy wiring options back and side wire capable
  • External back wire clamps provide visual indication of proper wire seating
  • Withstands high torque and resists wire pullout
  • Standard brass self-grounding clip
  • Trip threshold meets or exceeds UL requirements for tripping time
  • Improved immunity to high frequency noise reduces nuisance tripping
  • Advanced electronics design provides superior resistance to electrical surges and over voltages

Specification

Material
Polycarbonate/Thermoplastic
NEMA Rating
NEMA 5-20R
Number Of Poles
2
Number of Wires
3
Minimum Order Qty
1
Order Interval
1
Amperage Rating
20 A
Catalog ID
LEVGFRBF-W
Color
White
Dimensions
4.21 in H x 1.69 in W x 1.4 in D
Temperature Rating
-35 to 66 deg C
Terminal Type
Back/Side Wired
Type
Blank Self-Test Slim
Voltage Rating
125 VAC
Application
Residential Applications
Standard & Approvals
RoHS Compliant, ANSI C-73, CSA C22.2 No. 42, C22.2 No. 144.1-06 File No. LR57811, Federal Specification WC-596, NOM Certified, UL 943 File No.E48380
Includes
Self-Grounding Clip
Horsepower
1 hp
