SolaHD SDN16-12-100P SDN-P Compact Power Supply, 115/230 VAC Input, 12 VDC Output, 192 W Power Rating, 3.3/1.7 A, DIN Rail Mount

Selected SDN16-12-100PSolaHD SDN16-12-100P SDN-P Compact Power Supply, 115/230 VAC Input, 12 VDC Output, 192 W Power Rating, 3.3/1.7 A, DIN Rail Mount
SDN16-12-100PSolaHD SDN16-12-100P SDN-P Compact Power Supply, 115/230 VAC Input, 12 VDC Output, 192 W Power Rating, 3.3/1.7 A, DIN Rail Mount

Documents

Short Description

The SDN DIN Rail power supplies provide industry leading performance. Sag Immunity, transient suppression and noise tolerant, the SDN series ensures compatibility in demanding applications. Power factor correction to meet European directives, hazardous location approvals and optional redundant accessories allow the SDN series to be used in a wide variety of applications. Wide operation temperature range, high tolerance to shock and vibration and reliable design make the SDN series the preferred choice of users.

Features

  • Power Factor Correction
  • Improved metal mounting clip
  • DC OK Signal
  • Adjustable Voltage
  • Parallel Capability standard on all units
  • Industrial grade design
  • -10 to 60 deg C operation without derating. Indefinite short circuit, overvoltage and over temperature protection
  • Powers high inrush loads without shutdown or foldback
  • Rugged metal case and DIN connector
  • Narrow width on rail for space critical applications
  • User-friendly front pane
  • Large, rugged, accessible, multiple connection screw terminations
  • Easy installation
  • High MTBF and reliability
  • Screw terminal. 90 RH humidity range PCT
  • Internally fused
  • 16 - 10 AWG, -10 to 60 deg C operating
  • 84% efficiency
  • 12 VDC at 16 A
  • Single phase

Specification

Frequency Rating
47 - 63 Hz
Input Voltage
115/230 VAC
Mounting Type
DIN Rail
Output Voltage
12 VDC
Power Rating
192 W
Series
SDN-P
Application
For industrial machine control and process, conveying equipment, material handling, packaging equipment, vending machines, DeviceNet, amusement park equipment, semiconductor fabrication equipment
Standard & Approvals
CE Marked, CSA-C22.2 No. 60950-1, CUL Listed, UL (CANADA AND US) File No. E61379, RoHS Compliant, UL 508, 60950 Listed
Width
3.23 in
Height
5.63 in
Depth
4.55 in
Case Material
Metal
Amperage Rating
3.3/1.7 A
