SolaHD SDN20-24-100C SDN-C Compact Power Supply, 115/230 VAC Input, 24 VDC Output, 480 W Power Rating, 6/3 A, DIN Rail Mount

Selected SolaHD SDN20-24-100C SDN-C Compact Power Supply, 115/230 VAC Input, 24 VDC Output, 480 W Power Rating, 6/3 A, DIN Rail Mount
SolaHD SDN20-24-100C SDN-C Compact Power Supply, 115/230 VAC Input, 24 VDC Output, 480 W Power Rating, 6/3 A, DIN Rail Mount

Documents

Short Description

The SDN-C DIN rail power supplies are the next generation of the popular SDN series. These models combine high effi ciency and compact size with new visual diagnostic LEDs to offer the most performance available from SolaHD. Essential industrial features such as Sag Immunity, Power Factor Correction, and universal voltage input have been retained in this series. Wide temperature operating range and parallel operation capability make the new SDN-C units suitable to a variety of industrial applications.

Features

  • Compact packaging to save space on the DIN rail
  • Visual diagnostic LEDs for input and output status at a glance
  • High MTBF means high reliability and long life
  • Higher efficiency saves energy and lowers amount of heat generated in panel
  • PowerBoost overload capability to start high inrush loads
  • Active Power Factor Correction
  • Patented DIN rail mounting clip
  • User Adjustable output voltage accessible via front face
  • Parallel capability standard
  • Large, rugged, accessible screw terminals
  • Industrial grade design
  • Fully tested and burned-in at factory
  • Highly efficient switching technology
  • Active power factor correction to better than 0.92
  • Screw terminal. 90 RH humidity range PCT
  • 16 - 10 AWG, -25 to 60 deg C operating
  • 92% efficiency
  • 24 VDC at 20 A

Specification

Frequency Rating
43 to 67 Hz
Height
2-1/2 in
Input Voltage
115/230 VAC
Mounting Type
DIN Rail
Output Voltage
24 VDC
Minimum Order Qty
1
Order Interval
1
Case Material
Metal
Series
SDN-C
Type
Compact
Depth
9 in
Catalog ID
H-DSDN20-24-100C
Amperage Rating
6/3 A
Standard & Approvals
CB Certificate and report, CE Mark (LVD), CSA 22.2-234 Level 3 LR53982C, CSA 22.2 No. 601.1, EN 60601-18, Medical UL 2601, Non-Medical EN60950, RoHS Compliant, UL 60950 File No. E132002
Application
For use in industrial and medical applications requiring standard footprint size and very high reliability
Width
5 in
Power Rating
480 W
