Sta-Kon® 2RA18 Nylon Insulated Butt Splice Connector, 22 to 18 AWG Conductor, 1.19 in L, Copper, Red

Selected Sta-Kon® 2RA18 Nylon Insulated Butt Splice Connector, 22 to 18 AWG Conductor, 1.19 in L, Copper, Red
Sta-Kon® 2RA18 Nylon Insulated Butt Splice Connector, 22 to 18 AWG Conductor, 1.19 in L, Copper, Red

Documents

Short Description

Sta-Kon® wire terminals offer more copper and a wider funnel to assure premium connection with less work in a line that includes insulated and non-insulated terminals, splices, wire joints, disconnects, ferrules, heat-shrinkable terminals, splices and disconnects.

Features

  • Nylon insulated with electro tin plated
  • Wires are laid side by side in the connector and the splice connection is complete in one crimp
  • Color coded according to wire size
  • Nylon insulated splices meet or exceed the requirements of MIL-T-7928
  • 100/Pack, 500/Pack, Standard

Specification

Length
1.19 in
Material
Copper
Series
RA
Specifications
0.115 in Maximum Insulation Dia, 0.03 in Stock
Temperature Rating
105 deg C
Type
Insulated
Voltage Rating
600 VAC
Standard & Approvals
CSA Certified, RoHS Complaint, UL 94 V-2 Flammability Rating, UL Listed
Conductor Size
22 to 18 AWG
Dimensions
0.18 in W
Color
Red
Finish
Tin Plated
