Sta-Kon® AB14-10A AB Series Non-Insulated Flag Terminal, 22 to 14 AWG Conductor, 0.55 in L, Copper, Metallic

Selected Sta-Kon® AB14-10A AB Series Non-Insulated Flag Terminal, 22 to 14 AWG Conductor, 0.55 in L, Copper, Metallic
Sta-Kon® AB14-10A AB Series Non-Insulated Flag Terminal, 22 to 14 AWG Conductor, 0.55 in L, Copper, Metallic

Documents

Short Description

Sta-Kon® wire terminals offer more copper and a wider funnel to assure premium connection with less work in a line that includes insulated and non-insulated terminals, splices, wire joints, disconnects, ferrules, heat-shrinkable terminals, splices and disconnects.

Features

  • Flag terminals allow a 90 deg connection to the terminal block without bending the wire
  • Brazed seam joint

Specification

Length
0.55 in
Material
Copper
Stud Size
#10
Temperature Rating
302 deg F
Type
Non-Insulated
Voltage Rating
600 VAC
Standard & Approvals
UL Listed, CSA Certified, RoHS Compliant
Color
Gray
Finish
Electro-Plated Tin
Tongue Type
Flag
Tongue Size
0.31 in W x 0.22 in THK
Series
AB Series
Conductor Size
22 to 14 AWG
