Superstrut® Cobra® CPC350 700 1-Piece Conduit and Cable Clamp, 3-1/2 in Conduit, 350 lb Load, 3.626 to 4.126 in OD, Steel

Selected S SCPC350
S SCPC350

Documents

Short Description

Superstrut®, with a full compliment of fittings, hardware and accessories to complete any metal framing job, is the only system of its kind to provide multiple finishes for total corrosion protection.

Features

  • 1-piece, heavy duty construction ready to install right out of the box, no need to break apart and reassemble, no screws or bolts to drop
  • Heavy duty 5/16 in hex bolt with multi-driver head (Robertson square, Philips® cross-recess and slot) provides a full range of installation options
  • Reconfigure wiring without complete disassembly
  • Remove cables easily without disturbing neighboring clamps
  • Parallel hook design keeps conduits and cable square with strut
  • Works with all depth of strut 13/16 to 3-1/4 in
  • 2 hooks on the same side make the clamp easy to install and keep conduits and cable square with strut
  • Rugged stirrup and wide saddle design holds securely with no damage to conduit or cable

Specification

Load Capacity
350
Material
Steel
Mounting Type
Parallel Hook
Outside Diameter
3.626 to 4.126 in
Series
700
Specifications
35 ft-lb Torque
Suitable For Use With
EMT, Rigid Conduit and Cable
Type
1-Piece
Application
For attaching a full range of Rigid/EMT conduit and cable to strut channels
Standard & Approvals
ARRA, Buy American Act and RoHS Compliant, CSA Certified, UL Listed
Conduit Size
3/1/2002 12:00:00 AM
Finish
Electro-Galvanized/Silver Galvanized
