Hubbell, Straight Blade Receptacle, Duplex, 2 Pole, 3 Wire, 20 A, 125 V, White
Hubbell, Straight Blade Receptacle, Duplex, 2 Pole, 3 Wire, 20 A, 125 V, White
SKU: HWDCR20WHITR
Manufacturer Part Number: CR20WHITR
UPC: 783585144306
Documents
Features
- Easy access split circuit tab
- Fork terminal capable
- Smooth face, traditional face, triple wipe contacts
- NO 8 to 32 brass, multiple drive terminal screw material, NO 8 to 32 brass, multiple drive (green) ground screw material
- Nylon top and base material, 0.031 in (0.8) phosphor bronze power contacts material, 0.04 in (1) steel (galvanized) mounting strap material, 0.032 in (0.8) steel wire auto ground clip material
- Steel-zinc plated mounting screw material
- Withstands 2000 V minimum dielectric voltage
- Certified for current interrupting at full rated current
- Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75% temperature rise
- Terminals identified in accordance with UL 498 (brass, white, green)
- NO 14 to 10 AWG copper stranded or solid conductor only terminal accommodation
- UL 94V-2 flammability
Specification
| Grade | Specification |
|---|---|
| Material | Nylon |
| NEMA Rating | NEMA 5-20R |
| Number Of Poles | 2 |
| Number of Wires | 3 |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Amperage Rating | 20 A |
| Catalog ID | HWDCR20WHITR |
| Color | White |
| Dimensions | 1.32 x 1.14 x 3.28 in |
| Series | Commercial |
| Temperature Rating | -40 to 75 deg C |
| Terminal Type | Side Wired |
| Type | Grounding Tamper Resistant |
| Voltage Rating | 125 VAC |
| Application | For commercial specification grade applications |
| Standard & Approvals | UL 498, UL E2186 Listed, Meets NEMA WD-6, CSA C22.2, No 42 Certified |
| Horsepower | 1 hp |
