Wiring Device-Kellems AUTOGUARD® Style Line GFR8300SGI Decorator Duplex Heavy Duty Standard Self-Test Tamper/Weather Resistant GFCI Receptacle With LED Indicator, 125 VAC, 20 A, 2 Poles, 3 Wires, Ivory

Selected Wiring Device-Kellems AUTOGUARD® Style Line GFR8300SGI Decorator Duplex Heavy Duty Standard Self-Test Tamper/Weather Resistant GFCI Receptacle With LED Indicator, 125 VAC, 20 A, 2 Poles, 3 Wires, Ivory
Wiring Device-Kellems AUTOGUARD® Style Line GFR8300SGI Decorator Duplex Heavy Duty Standard Self-Test Tamper/Weather Resistant GFCI Receptacle With LED Indicator, 125 VAC, 20 A, 2 Poles, 3 Wires, Ivory

Documents

Short Description

Hubbell AUTOGUARD GFCI receptacles continually test and monitor for people protection capability automatically. This patented safety feature includes disconnecting power to the receptacle if critical components are damaged and GFCI protection is lost. GFCI auto-monitoring is conducted continuously within every 30 seconds. Also, clear visual indicators are provided on the device face representing power status, trip condition, ground fault condition and end of life status. In addition, for added safety, power will be denied to the receptacle face if reverse wiring of line and load was to occur.

Features

  • 10 kA short circuit current rating
  • Limits improper access to energized contacts
  • Power indication
  • Ground fault indicator
  • No power at face if reverse wired

Specification

Frequency Rating
60 Hz
Grade
Commercial/Hospital
Material
Composite/Polybutylene Terephthalate/Thermoplastic
NEMA Rating
NEMA 5-20R
Number Of Poles
2
Number of Wires
3
Minimum Order Qty
1
Order Interval
1
Video
https://www.youtube.com/watch?v=47pyepHCQ1w
Amperage Rating
20 A
Catalog ID
HWDGFR8300SGI
Color
Ivory
Dimensions
1.75 in W x 1.47 in D
Temperature Rating
-30 to 150 deg F
Terminal Type
Back and Side Wired/Screw
Type
Decorator Duplex Heavy Duty Standard Self-Test Tamper/Weather Resistant
Voltage Rating
125 VAC
Application
Dry Locations and Indoor Applications
Standard & Approvals
ANSI 73, UL 498, 943, File No. E41978, CSA Certified, NEMA WD1, WD5, WD6, NEC, CEC, ARRA, Buy American Act Compliant, Federal Specification
Horsepower
1 hp
