Hubbell, Straight Blade Receptacle, Single, 2 Pole, 3 Wire, 30 A, 250 V, Black
Hubbell, Straight Blade Receptacle, Single, 2 Pole, 3 Wire, 30 A, 250 V, Black
SKU: HWDHBL9330
Manufacturer Part Number: HBL9330
UPC: 783585015231
Documents
Features
- 3 wire grounding
- Withstands 2000 V minimum dielectric voltage
- Certified for current interrupting at full rated current
- Catalog number, ratings and certifications molded in face
- Sequenced contacts assure protection
- One-piece design power and ground contacts
- 10 - 4 AWG copper stranded or solid conductor only
- UL 94 V-0 flammability
- Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150 percent of rated current at a power factor of 75 percent
- Terminals identified in accordance with UL 498 and CSA
- Plated steel terminal and ground screw material
- Phenolic top material
- Brass power contacts material, phenolic top and base
- 0.062 in plated steel mounting strap material
- Steel-zinc plated mounting screw
- Brass box terminals material
- Traditional face
Specification
| Grade | Specification |
|---|---|
| Material | Phenolic |
| Number Of Poles | 2 |
| Number of Wires | 3 |
| Temperature Rating | -40 to 75 deg C |
| Terminal Type | Back and Side Wire |
| Type | Heavy Duty Grounding |
| Voltage Rating | 250 VAC |
| Standard & Approvals | UL File No. E2186, CSA Certified |
| Amperage Rating | 30 A |
| Color | Black |
| Enclosure | IP20 |
| Horsepower | 2 hp |
| NEMA Rating | NEMA6-30R |
| Dimensions | 3.28 x 2.25 x 2.23 in |
