Wiring Device-Kellems tradeSELECT® RR350 Dryer Range Power Receptacle Without Ground, 125/250 VAC, 50 A, 3 Poles, 3 Wires, Black
Wiring Device-Kellems tradeSELECT® RR350 Dryer Range Power Receptacle Without Ground, 125/250 VAC, 50 A, 3 Poles, 3 Wires, Black
SKU: HWSRR350
Manufacturer Part Number: RR350
UPC: 883778100840
Features
- Eliminates the need to loop the wire
- External back wire clamp for fast, easy and secure installation of 20 A circuits in residential applications
- Compression plates maximize holding power to provide stronger, more secure connections for 12 AWG wiring
- Terminate up to 8 wires for downstream circuits
- Break-off tabs for switched receptacle applications
- Tamper-resistant shutter complies with national electrical code requirements
- Surface mount
Specification
| Material | Composite/Thermoplastic |
|---|---|
| NEMA Rating | NEMA 10-50R |
| Number Of Poles | 3 |
| Number of Wires | 3 |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Amperage Rating | 30 A |
| Catalog ID | HWSRR350 |
| Color | Black |
| Dimensions | 2.5 in W x 2.21 in D x 5.49 in H |
| Temperature Rating | 75 deg C |
| Terminal Type | Pressure Screw |
| Type | Dryer Range |
| Voltage Rating | 125/250 VAC |
| Application | For residential applications |
| Standard & Approvals | UL Listed, CSA Certified |
