Hubbell, Cord Connector, Straight, Male, 3/4 Inch, Nylon, 0.50 to 0.63 Inch
Hubbell, Cord Connector, Straight, Male, 3/4 Inch, Nylon, 0.50 to 0.63 Inch
SKU: HWDSHC1036CR
Manufacturer Part Number: SHC1036CR
UPC: 783585208084
Documents
Features
- Hubbell's nylon cord connectors resist most common industrial corrosive and provide effective pullout protection in a lightweight design
- They are ideal for any application where weight, conductivity or corrosion may be an issue
- Nylon cord connectors resist corrosion
- Tapered interior seats the bushing evenly for a liquid tight seal
- Connector body is a one piece design with machined threads
- F3 form size
- Hubbell nylon cord connectors have a UL 94-V2 rating flammability
- Hubbell cord connectors are suitable for use in hazardous locations per Class I Div. 2, Class II Div. 1 and 2, Class III Div. 1 and 2 N.E.C Reference 501-4(b), 502-4(a), 502-4(b), 503-3(a), and 503-3(b)
- 1.09 to 1.14 in (27.8 to 29) recommended knockout hole size
- 0.55 in length thread
- 0.77 in diameter throat
Specification
| Material | Nylon |
|---|---|
| Series | SHC |
| Temperature Rating | -30 to 225 deg F |
| Trade Size | 3/4 in |
| Standard & Approvals | UL 514B Listed, CSA Certified, United States Coast Guard Approval, Title 46-Part 111 |
| Cable Openings | 0.5 to 0.63 in |
| Color | Brown |
| Finish | Smooth |
| Connection Type | Straight MNPT |
| Dimensions | 2.15 x 1.56 x 1.56 in |
